Compact • Secure • Aesthetically Pleasing
This is the most popular premium residential roller shutter in our range it is the most compact and neatest looking and most secure residential roller shutter it also has the title of Australia’s best looking roller shutter
- Description
- Tech Specs
- Components
- Comparison
- Colours
- Gallery
What seperates Slimline from other shutters
- Aesthetics: excellent styling Slim pelmet box, 14 top Colorbond colours
- Excellent for: home security, light blocking, noise reduction, climate control, energy savings
- Good for: glare reduction light control and light blocking
Slimline Roller Shutter Benefits
- Up to 80% noise reduction
- Up to 15° cooler in summer
- Up to 15° warmer in winter
- Up to 98% light block out
- Up to 40% more energy efficient
- Secure, built-in locking mechanism
- Eliminates condensation
- Reduces glare
- Rust prevention: 95% components aluminium
Suitable Applications
- Residential Windows
- Residential Doors
- Kitchen Serveries
- Internal Room Dividers
- Internal Storage Cabinets
- Light Commercials Shop Fronts
Technical Specifications
Maximum Height | 3600 mm |
---|---|
Maximum Width | 3600 mm |
Curtain Weight | 3.8 kg per m2 |
Profile Size | 45mm x 9mm x 0.33mm Aluminium |
Standard Guides | 54mm x 22mm x 1.2mm Aluminium |
Extended Guides | 70mm x 23mm x 2.5mm Aluminium |
Bottom Bar | 52mm x 8mm x 1.1mm Aluminium |
Axle | 57mm x 2.1mm Aluminium |
Pelmet Chart
Max Height (Including Pelmet Box) | Pelmet Size |
---|---|
1300mm | 150mm x 150mm |
1700mm | 165mm x 165mm |
2135mm | 180mm x 180mm |
3000mm | 205mm x 205mm |
3400mm | 230mm x 205mm |
Profile
- Type: 45 mm x 9 mm x 0.33 mm Aluminium Interlocking slats
- Insulation: Polyurethane filled
- Brand: Pracal
- Country of Origin: Italy
Pelmet
- Type: 0.78 mm Aluminium
- Brand: Expalum
- Country of Origin: Spain
Motor
- Type: 240 volt mains tubular
- Brand: ASA
- Country of origin: Italy
Benefit | Slimline | Titan | Cyclone | Patiomate | Maxspan | Clear Polycarb | Manual Push Pull |
---|---|---|---|---|---|---|---|
Security | ⭐⭐⭐ | ⭐⭐⭐⭐⭐ | ⭐⭐⭐⭐ | ⭐⭐⭐⭐ | ⭐⭐⭐⭐⭐ | ⭐⭐ | ⭐⭐⭐ |
Summer Insulation | ⭐⭐⭐⭐⭐ | ⭐⭐⭐ | ⭐⭐⭐⭐⭐ | ⭐⭐⭐⭐⭐ | ⭐⭐⭐⭐⭐ | ⭐⭐ | ⭐⭐⭐⭐ |
Winter Insulation | ⭐⭐⭐⭐⭐ | ⭐⭐⭐ | ⭐⭐⭐⭐⭐ | ⭐⭐⭐⭐⭐ | ⭐⭐⭐⭐⭐ | ⭐⭐⭐ | ⭐⭐⭐⭐ |
Noise Reduction | ⭐⭐⭐⭐ | ⭐⭐⭐ | ⭐⭐⭐⭐⭐ | ⭐⭐⭐⭐⭐ | ⭐⭐⭐⭐⭐ | ⭐⭐⭐ | ⭐⭐⭐ |
Privacy | ⭐⭐⭐⭐⭐ | ⭐⭐⭐⭐⭐ | ⭐⭐⭐⭐⭐ | ⭐⭐⭐⭐⭐ | ⭐⭐⭐⭐⭐ | ⭐ | ⭐⭐⭐⭐⭐ |
Light Control | ⭐⭐⭐⭐⭐ | ⭐⭐⭐⭐⭐ | ⭐⭐⭐⭐⭐ | ⭐⭐⭐⭐⭐ | ⭐⭐⭐⭐⭐ | ⭐ | ⭐⭐⭐⭐⭐ |
Energy Savings | ⭐⭐⭐⭐ | ⭐⭐⭐ | ⭐⭐⭐⭐⭐ | ⭐⭐⭐⭐⭐ | ⭐⭐⭐⭐⭐ | ⭐⭐⭐ | ⭐⭐⭐ |
Bushfire Protection | ⭐⭐ | ⭐⭐⭐ | ⭐⭐ | ⭐⭐ | ⭐⭐ | ⭐ | ⭐⭐ |
Wind Protection | ⭐⭐⭐ | ⭐⭐⭐⭐⭐ | ⭐⭐⭐⭐ | ⭐⭐⭐ | ⭐⭐⭐⭐ | ⭐⭐ | ⭐⭐⭐ |
Slat Colors
Blue Ridge
Classic Cream
Deep Ocean
Dune
Evening Haze
Gully
Jasper
Monument
Paperbark
Shale Grey
Surfmist
Natural White
Woodland Grey
Night Sky Black
